Metal stairs CORA model Mix 250 lux U-180 15 elements

Metal stairs CORA model Mix 250 lux U-180 15 elements

The Mix 250 lux model is a self-assembly staircase.

The set includes 15 elements of stairs, folded into 16 levels. The elements are made of solid wood (color to choose from the manufacturer's color palette) and powder coated steel in satin steel color. After ordering the service for an additional fee, professional installation in the country is carried out by the manufacturer.

Metal stairs as a modern application in construction replace traditional wooden stairs with modern ones.

The Mix 250 lux stairs can be installed in one of 78 configurations, which are fully presented by the manufacturer. This model has original U-180 treatment, both right and left. It is possible to order a simple procedure after adding annotations to the order form.

It is recommended to install the stairs next to the wall, up to 5 cm from it, which allows the installation of anchors. If the wall cannot withstand the anchoring, a supporting column should be used instead. For free-standing stairs, it is planned to use a supporting column, as well as a balustrade protecting both sides, additional options on request.

Description, Parameters, Application
Application: internal stairs (inside the building)
Load capacity: maximum load per step 180 kg
Weight: Set of stairs / set of 15 elements 250 kg
Type of stairs: single-beam stairs (modular)
Type of application: modular stairs, universal arrangement and application, straight, left-handed, right-handed
Type of rooms: for small, medium and large rooms
Construction type: modular metal 220
Wood finish: included in the price of the stairs (reference photo on beech, BR-335) or stained in a selected color from the wood color palette
Configuration, layouts: U-180 stairs can be used in 78 layouts
Railing type: 12 mm INOX tube filling (4 pcs.)
Manufacturer: Polish manufacturer of modular, metal stairs, CORA system

Technical description
height: 280 / 368 cm,
number of elements: 15 steps / 16 heights,
step height: adjustable 17.5 / 23.0 cm,
straight step size: 300 (220+80) mm
step thickness: 40 mm

opening in the ceiling: minimum 1720 x 1580 mm

metal color: steel satin
run width:
- treatment U-180: 900 / 900 / 900 mm
type of wood: solid beech,
wood color: in the price of the stairs, an illustrative photo of the stairs (on beech, beech BR-335) Other colors to choose from the wood color palette
Modular construction: 250 metal
One-sided balustrade / polished stainless steel
posts (wood-metal) 38 mm
recessed into the steps / every other
tube filling 12 mm INOX (4 pcs.)
wood handrail 50 mm

Sample heights, sizes
Floor to floor 193 - 253 cm - 10 steps / 11 heights (- 5 steps)
Floor to floor 210 - 276 cm - 11 steps / 12 heights (- 4 steps)
Floor to floor 228 - 299 cm - 12 steps / 13 heights (- 3 steps)
Floor to floor 245 - 322 cm - 13 steps / 14 heights (- 2 steps)
Floor to floor 263 - 345 cm - 14 steps / 15 heights (- 1 step)
Floor to floor 280 - 368 cm - 15 degrees / 16 heights (standard)

Additional information

Important information regarding the safety of use and use of the stairs:
The stairs should run partly against the wall. They must not be moved away from the wall by more than 5 cm. This is related to the safety of using the stairs. It is necessary to apply the anchor to the wall.
If the stairs are free-standing, it is recommended to use:
- support pole,
- balustrade on both sides of the stairs,

Custom-made stairs to be agreed:
If it is not possible to match the stairs according to the configurations below, we will make custom-made stairs.
We will prepare a design and valuation of stairs based on:
- sent projections of the cross-section of the building with actual dimensions,
- or making a sketch with actual dimensions and sending it to the e-mail address: [email protected]
We will prepare a special offer in our online store in the category: made to order.

Time limit for completion
- Delivery of stairs without assembly - 2 / 3 weeks
- Delivery of stairs with assembly - 4 / 6 weeks
